※ W250H01-0.65
| Applicable Wire Gauge: | AWG28#～/22# |
| Applicable PCB Thickness: | 1.6mm |
※ SPECIFICATION
| Temperature Range | 25℃～85℃ |
| Rated Voltage | 250V AC/DC |
| Rated Current | 3A |
| Contact Resistance | <0.02Ω |
| Insulation Resistance | >1000MΩ |
※ DIAGRAM
