Funtion: ON-OFF
Contact Arrangement: 1P3T, Normally Open
Termination: THD version
Operating Temperature: -25～+70℃
Relative Humidity: (40℃)≤95%
Contact Rating: 0.3A 50V DC
Dielectric Strength: 250VAC/1min
Contact Resistance: 100mΩ Max.
Insulation Resistance: 100MΩ Min.
Travel: 2±0.2mm
※ SK09
| Funtion: | ON-OFF |
| Contact Arrangement: | 1P3T, Normally Open |
| Termination: | THD version |
※ SPECIFICATION
| CONTACT RATING | 0.3A 50V DC | |
| CONTACT RESISTANCE | 100mΩ Max. | |
| INSULATION RESISTANCE | 100MΩ Min. | |
| DIELECTRIC STRENGTH | 250VAC/1min | |
| LIFE EXPECTANCY | 5000 cycles | |
| TRAVEL | 2±0.2mm | |
※ DIAGRAM
