Funtion: ON-OFF
Contact Arrangement: 1P3T,Normally Open
Termination: THD version
Operating Temperature: -25～+70℃
Relative Humidity: (40℃)≤95%
Contact Rating: 0.3A 50V DC
Dielectric Strength: 250VAC/1min
Contact Resistance: 100mΩ Max.
Insulation Resistance: 100MΩ Min.
Travel: 2±0.2mm
Actuation Force: 250±100gf
Life Expectancy: 5000
※ SS07
| Funtion: | ON-OFF |
| Contact Arrangement: | 1P3T, Normally Open |
| Termination: | THD version |
※ SPECIFICATION
| Contact Rating | 0.3A 50V DC |
| Dielectric Strength | AC250V for 1 Minute |
| Contact Resistance | 100 mΩ Max. |
| Insulation Resistance | 100MΩ Min. |
| Life Expectancy | 5000 |
| Travel | 2±0.2mm |
※ DIAGRAM
_00 - 副本.jpg)
_00.jpg)
